This 4-axis Makino a81 horizontal machining center was manufactured in 2008. It offers robust capabilities for precision machining. Consider the opportunity to buy this Makino a81 horizontal machining center. Contact us for more information.
Location: DE
Control Brand: MAKINO
Control Model: Pro5
Table Load: 1200 kg
Transverse movement (x-axis) of the column: 900 mm
Height adjustment (y-axis) of the spindle unit: 800 mm
Longitudinal movement (z-axis) of the table: 1020 mm
Permissible swivel diameter in the working area: 1000 mm
Max. Swiveling height from pallet surface: 1300 mm
Pallet size: 630 x 630 mm
Input resolution: 0. 001°
Positioning accuracy: ± 3 arcseconds
Power Supply 400 V, 3-phase AC, 50 Hz Power rating: 72 kVA Control System Options for 48 zero points and Custom Macro B Tool life monitoring Tool breakage detection Adaptive feed control Compressed air through the spindle Knoll compact band filter, 3200 liters Magnetic separator Double-switching filter for IKZ Coolant supply through the spindle Compressed air through the spindle Oil mist extraction Scraper belt conveyor Control System: Makino Pro5 Options for 48 zero points and Custom Macro B Tool life monitoring Tool breakage detection (parallel to main operation) Adaptive feed control Conversion Kit for Stand-Alone Operation (Currently used as a system machine (FFS/FMS)) Pallet changer with placement of 2 pallets in alternating cycles onto a station positioned outside the working area Pallet holder rotatable, indexed at 90° intervals, 0-position electronically monitored Coding for automatic program call when inserting the pallet Pallet storage station secured with a protective device and electrical interlock
Additional equipment
Spindle cooling
Tank system with Knoll compact band filter
3200 liters
Coolant supply through the spindle
Oil mist extraction
Scraper belt conveyor
Conversion kit for stand-alone operation (currently used as a system machine)
Machine Benefits
Technical Machine Benefits
Pallet – nc – rotary table with 4th nc axis
Tool magazine with 242 storage slots
